產品名稱：FSY-YSY 2×14# Rodent & Termite Resistant Cable
瀏覽：
添加時間：2026-05-22 10:13:36
推薦度：

介紹：

FSY-YSY 2×14# 防鼠防蟻電纜

FSY-YSY 2×14# Rodent & Termite Resistant Cable

FSY-YSY 2×14# 是一款額定電壓 0.6/1kV 的銅芯防鼠防蟻特種電纜。該產品采用環保型聚烯烴護套，通過添加專用防鼠劑與防白蟻劑，專為鼠害、蟻害嚴重的環境設計，廣泛應用于地下管廊、隧道及潮濕腐蝕性場所的電力傳輸。

FSY-YSY 2×14# is a copper-core rodent and termite resistant cable with a rated voltage of 0.6/1kV. It utilizes an environmentally friendly polyolefin sheath with specialized rodent and termite repellents, designed for environments with severe pest infestations such as underground utility tunnels, subways, and corrosive damp locations.

一、產品規格概要

I. Product Specification Summary

項目	具體描述
完整型號	FSY-YSY 2×14# (或 2×14AWG)
產品類型	銅芯聚烯烴絕緣及護套防鼠防蟻電纜
額定電壓	0.6/1 kV
芯數與截面	2 芯，標稱截面 14# (約 2.08 mm2)
典型結構	銅導體 + 聚烯烴絕緣 + 聚烯烴防鼠蟻?zhàn)o(hù)套
Item	Specific Description
:---	:---
Complete Model	FSY-YSY 2×14# (or 2×14AWG)
Product Type	Copper Conductor, Polyolefin Insulated & Sheathed Rodent & Termite Resistant Cable
Rated Voltage	0.6/1 kV
Core Number & Cross-Section	2 cores, nominal cross-sectional area 14# (approx. 2.08 mm2)
Typical Structure	Copper Conductor + Polyolefin Insulation + Polyolefin Rodent/Termite Resistant Sheath

二、主要技術參數

II. Main Technical Parameters

參數類別	技術說明
導體	銅導體，截面 14# (約 2.08 mm2)，柔韌性好
絕緣/護套	環保型聚烯烴材料，耐腐蝕、耐潮濕
防鼠蟻機制	護套添加環保驅避劑 (如 DH-600/DH-203)，驅避鼠類、滅殺白蟻
溫度范圍	長期工作 ≤+90℃，環境適應 -25℃ ~ +45℃
彎曲半徑	多芯電纜 ≥15D (D為電纜外徑)
Parameter Category	Technical Description
:---	:---
Conductor	Copper conductor, 14# gauge (approx. 2.08 mm2), good flexibility
Insulation/Sheath	Eco-friendly polyolefin, corrosion and moisture resistant
Pest Resistance	Sheath contains eco-repellents (e.g., DH-600/DH-203) to deter rodents and kill termites
Temperature Range	Long-term operating ≤+90℃, ambient -25℃ ~ +45℃
Bending Radius	Multi-core cable ≥15D (D is outer diameter)

三、產品核心特點

III. Core Product Features

雙重防護：護套中添加防鼠劑與防白蟻劑，通過驅避或滅殺機制，有效防止鼠類啃咬與白蟻蛀蝕，保護電纜結構完整。
環保安全：采用低毒或無毒環保添加劑，對土壤、空氣污染小，符合綠色電纜要求。
環境適應強：聚烯烴材質具備優異的耐候性、耐磨性及耐化學腐蝕性，適用于潮濕、酸堿等復雜環境。
電氣性能穩定：絕緣電阻大，耐電壓性能好，確保在惡劣環境下電力傳輸?shù)目煽啃浴?/span>
Dual Protection: The sheath contains rodent and termite repellents that deter chewing and boring through repellency or lethal action, ensuring structural integrity.
Environmental Safety: Utilizes low-toxicity or non-toxic eco-friendly additives, minimizing pollution and meeting green cable standards.
Environmental Resistance: Polyolefin material offers excellent weather, abrasion, and chemical corrosion resistance, suitable for damp and corrosive conditions.
Stable Electrical Performance: High insulation resistance and good voltage withstand capability ensure reliable power transmission in harsh environments.

四、典型應用領域

IV. Typical Application Fields

地下基礎設施：城市地下綜合管廊、電纜隧道、地鐵及地下變電站，防止鼠蟻破壞導致短路。
工業與能源：化工園區、發電廠、污水處理廠等存在腐蝕與生物危害的場所。
交通設施：鐵路信號系統、公路隧道照明、橋梁涵洞的供電線路。
農林水利：農田灌溉、泵站、水利樞紐等鼠蟻活動頻繁的戶外或半戶外區域。
Underground Infrastructure: Urban utility tunnels, cable tunnels, subways, and underground substations to prevent pest-induced failures.
Industrial & Energy: Chemical plants, power plants, and wastewater treatment plants where corrosion and pests are concerns.
Transportation: Railway signaling, highway tunnel lighting, and bridge culvert power supply lines.
Agriculture & Water Conservancy: Farm irrigation, pumping stations, and hydraulic projects with high pest activity.
