產品名稱：WDZC-FSY11-KVVP2-23 LSZH Anti-Rodent & Anti-Termite Cont
瀏覽：
添加時間：2026-05-19 10:57:55
推薦度：

介紹：

WDZC-FSY11-KVVP2-23 防鼠蟻電纜是一種專為復雜工業環境設計的特種控制電纜。該電纜在具備優異電氣性能與機械防護能力的同時，通過復合防鼠蟻結構設計，有效解決了電纜在戶外、地下或潮濕環境中被生物破壞的行業痛點。其采用的低煙無鹵護套材料在火災發生時能大幅降低有毒煙霧排放，是現代工業與基礎設施建設中關鍵的安全連接組件。

WDZC-FSY11-KVVP2-23 Anti-Rodent & Anti-Termite Cable Product Description

The WDZC-FSY11-KVVP2-23 Anti-Rodent & Anti-Termite Cable is a specialized control cable engineered for complex industrial environments. While delivering excellent electrical performance and mechanical protection, it incorporates a composite anti-rodent and anti-termite structural design to effectively address the industry-wide challenge of biological damage in outdoor, underground, or humid settings. Utilizing a Low Smoke Zero Halogen (LSZH) sheath material, it significantly reduces toxic smoke emissions during fire incidents, serving as a critical safety link in modern industrial and infrastructure projects.

核心特點 (Core Features)

1. 生物防護性能 (Biological Protection Performance)

主動防御機制：電纜外層采用特種防護配方或物理硬化處理，能夠有效抵御鼠類啃咬和白蟻蛀蝕，顯著降低因生物侵害導致的短路與停電風險。
長效環境適應性：防護層性質穩定，不溶于水且不揮發，在長期埋地或管廊敷設環境中保持持久的驅避效果。
1. Biological Protection Performance
Active Defense Mechanism: The outer layer employs specialized protective compounds or physical hardening treatments to effectively resist gnawing by rodents and boring by termites, significantly mitigating the risk of short circuits and power outages caused by biological damage.
Long-term Environmental Adaptability: The protective layer remains chemically stable, insoluble in water, and non-volatile, maintaining persistent repellent efficacy in long-term buried or utility tunnel installation environments.

2. 阻燃與環保特性 (Flame Retardant & Environmental Properties)

WDZC 級安全標準：符合無鹵、低煙、阻燃C類標準。在燃燒狀態下，電纜不釋放鹵酸等腐蝕性氣體，且煙密度極低，為人員疏散和應急救援提供清晰的能見度。
綠色材料應用：護套材料不含鉛、鎘等重金屬，符合 RoHS 環保指令要求。
2. Flame Retardant & Environmental Properties
WDZC Safety Standard: Complies with halogen-free, low smoke, and Class C flame retardant standards. Under combustion conditions, the cable does not emit corrosive halogen acid gases and exhibits minimal smoke density, providing clear visibility for personnel evacuation and emergency rescue operations.
Green Material Application: The sheath material is free from heavy metals such as lead and cadmium, meeting the requirements of RoHS environmental directives.

3. 電氣與屏蔽性能 (Electrical & Shielding Performance)

抗電磁干擾：采用銅帶屏蔽結構，形成法拉第籠效應，有效隔離外界強電磁場干擾，確?？刂菩盘杺鬏?shù)臏?zhǔn)確性與穩定性。
穩定傳輸：適用于額定電壓 450/750V 及以下的控制、監視回路及保護線路。
3. Electrical & Shielding Performance
Electromagnetic Interference Resistance: Featuring a copper tape shielding structure that creates a Faraday cage effect, effectively isolating external strong electromagnetic field interference and ensuring the accuracy and stability of control signal transmission.
Stable Transmission: Suitable for control, monitoring circuits, and protection lines with a rated voltage of 450/750V and below.

4. 機械防護能力 (Mechanical Protection Capability)

鋼帶鎧裝加固：內層設置鋼帶鎧裝層，具備******的抗壓、抗沖擊及抗拉能力，可適應直埋敷設或存在重型機械作業的嚴苛場景。
4. Mechanical Protection Capability
Steel Tape Armor Reinforcement: An inner steel tape armor layer provides exceptional resistance to compression, impact, and tension, adapting to harsh installation scenarios involving direct burial or operations with heavy machinery.

技術參數 (Technical Parameters)

參數項目 (Parameter)	參數值 (Specification)
產品名稱 (Product Name)	WDZC-FSY11-KVVP2-23 防鼠蟻控制電纜 WDZC-FSY11-KVVP2-23 Anti-Rodent & Anti-Termite Control Cable
額定電壓 (Rated Voltage)	450/750V
導體材質 (Conductor Material)	退火銅 (Annealed Copper)
絕緣材料 (Insulation Material)	聚氯乙烯 (PVC) / 交聯聚乙烯 (XLPE)
屏蔽結構 (Shielding)	銅帶屏蔽 (Copper Tape Shield)
鎧裝結構 (Armor Structure)	雙層鋼帶鎧裝 (Double Steel Tape Armor)
護套特性 (Sheath Characteristics)	低煙無鹵、防鼠、防白蟻 (LSZH, Anti-Rodent, Anti-Termite)
工作溫度 (Operating Temp.)	導體長期工作溫度 ≤ 70℃ / 90℃ (依絕緣層而定) Long-term conductor operating temperature ≤ 70℃ / 90℃ (depending on insulation)

典型應用場景 (Typical Application Scenarios)

能源電力 (Energy & Power)：發電廠、變電站、新能源（光伏、風電）項目的控制與保護線路。
重工業制造 (Heavy Industry)：冶金、化工、石油開采等存在腐蝕性氣體或鼠蟻?zhàn)躺闹毓I(yè)環境。
基礎設施 (Infrastructure)：城市軌道交通（地鐵）、高鐵信號控制系統，以及智能樓宇的消防安?；芈?。
通信交通 (Telecommunications & Transport)：通信基站的電源與控制連接，隧道照明及監控系統。
Typical Application Scenarios
Energy & Power: Control and protection lines for power plants, substations, and new energy projects (photovoltaic, wind power).
Heavy Industry: Heavy industrial environments prone to corrosive gases or rodent/termite infestations, such as metallurgy, chemical processing, and petroleum extraction.
Infrastructure: Urban rail transit (subway), high-speed rail signaling systems, and fire safety/security circuits in smart buildings.
Telecommunications & Transport: Power and control connections for communication base stations, tunnel lighting, and monitoring systems.
